| 材质 |
1 |
Stainless Steel SCS13/SCS14/SCS16. |
| 2 |
Cast Iron FC200. |
| Ductile Iron FCD450 (For HC Series Pumps). |
| Pump model is VCF in case of cast-iron material. |
| 3 |
Other specific materials. |
| SCS23, Nickel Alloy, Worthite, Hastelloy. |
| 温度 |
0oC～80oC |
|
| 轴承 |
Upper side: |
Ball Bearings (Oil Lubricated) |
| Lower side: |
Sleeve metal (External flushing) |
| 最大长度 |
Installed length starting from 6m, configurable to available installation space. |
|
| (size L) |
|
|
| Flange Rating |
JIS10K RF Tap hole. |
|
